Sottotappo conico

Codice serie: STC-PCR
Materiale:
PCR PE-LD
Colore: Blu

Stampa Scheda
Contattaci per maggiori informazioni o per richiedere campioni

    Serie Codice Evidenzia d1 d2 h D Inserito in un filetto femmina Inserito in un filetto maschio
    STC-PCR STC2.9-PCR 0 2.9 4.6 9.5 7.9 - -
    STC-PCR STC4.4-PCR 0 4.4 6.1 9.5 9.5 M6, 1/4'' UNF M4
    STC-PCR STC4.7-PCR 0 4.7 8.5 22.5 11.7 - -
    STC-PCR STC5.6-PCR 0 5.6 7.0 8.4 10.5 - -
    STC-PCR STC6.2-PCR 0 6.2 7.6 9.5 11.1 M8, 5/16'' UNF M5/M6
    STC-PCR STC7.7-PCR 0 7.7 9.3 8.0 12.7 - 1/4'' UNF
    STC-PCR STC7.7B-PCR 0 7.7 9.1 9.5 12.7 3/8'' UNF -
    STC-PCR STC8.4-PCR 0 8.4 10.0 9.5 13.5 M10, 1/8'' GAS, 7/16'' UNF M8, 5/6'' UNF
    STC-PCR STC8.6-PCR 0 8.6 10.3 9.8 13.7 - -
    STC-PCR STC9-PCR 0 9.0 10.7 11.5 13.9 - -
    STC-PCR STC9.4-PCR 0 9.4 10.8 8.5 14.0 - -
    STC-PCR STC10-PCR 0 10.0 11.8 9.5 15.0 M12 M10, 3/8'' UNF
    STC-PCR STC10.6-PCR 0 10.6 12.2 9.8 15.6 - -
    STC-PCR STC10.9-PCR 0 10.9 12.3 9.3 15.9 1/4'' GAS, 1/2'' UNF 1/8'' GAS
    STC-PCR STC11.2-PCR 0 11.2 14.0 18.5 17.5 - -
    STC-PCR STC11.3-PCR 0 11.3 12.9 8.5 16.3 - -
    STC-PCR STC11.3B-PCR 0 11.3 13.2 11.0 17.0 - -
    STC-PCR STC11.5-PCR 0 11.5 13.0 9.5 16.7 M14 -
    STC-PCR STC12-PCR 0 12.0 14.8 11.0 17.5 - -
    STC-PCR STC12.1-PCR 0 12.1 13.9 11.0 17.5 9/16'' UNF M12
    STC-PCR STC12.5-PCR 0 12.5 14.0 8.9 17.5 - 7/16'' UNF
    STC-PCR STC12.8-PCR 0 12.8 15.1 23.1 18.5 - -
    STC-PCR STC13.6-PCR 0 13.6 15.3 11.2 19.0 M16, 5/8'' UNF 1/4'' GAS, 1/2'' UNF
    STC-PCR STC14.2-PCR 0 14.2 16.0 12.1 19.0 3/8'' GAS M14, 9/16'' UNF
    STC-PCR STC14.7-PCR 0 14.7 17.0 12.7 20.6 M18 -
    STC-PCR STC14.9-PCR 0 14.9 16.4 11.5 21.0 - -
    STC-PCR STC15.5-PCR 0 15.5 17.1 8.5 20.6 - -
    STC-PCR STC16.1-PCR 0 16.1 17.6 8.5 21.0 - -
    STC-PCR STC16.4-PCR 0 16.4 18.3 12.3 22.2 M20, 3/4'' UNF M16, 5/8'' UNF
    STC-PCR STC16.6-PCR 0 16.6 18.5 13.0 21.9 - -
    STC-PCR STC17.1-PCR 0 17.1 19.4 13.0 22.0 M20 x 1.5 3/8'' GAS
    STC-PCR STC17.2-PCR 0 17.2 20.2 18.0 24.2 - -
    STC-PCR STC17.5-PCR 0 17.5 20.1 14.5 24.0 1/2'' GAS M18 x 1.5, M18 x 2
    STC-PCR STC17.7-PCR 0 17.7 19.6 12.7 22.2 M20 3/8'' GAS
    STC-PCR STC17.8-PCR 0 17.8 20.0 13.4 23.8 1/2'' GAS M18
    STC-PCR STC18.3-PCR 0 18.3 21.4 17.5 25.4 - -
    STC-PCR STC18.5-PCR 0 18.5 20.9 14.3 24.6 M22 3/4'' UNF
    STC-PCR STC19-PCR 0 19.0 21.5 14.3 25.8 M22, 7/8'' UNF -
    STC-PCR STC19.4-PCR 0 19.4 22.5 19.0 26.5 - -
    STC-PCR STC20.5-PCR 0 20.5 23.2 17.5 27.2 - -
    STC-PCR STC21.2-PCR 0 21.2 23.2 12.3 27.3 M24 -
    STC-PCR STC21.3-PCR 0 21.3 23.2 15.9 27.0 5/8'' GAS M20, 1/2'' GAS
    STC-PCR STC22-PCR 0 22.0 24.8 17.0 29.0 - M22 x 2
    STC-PCR STC22B-PCR 0 22.0 25.0 15.9 28.5 1'' UNF M22
    STC-PCR STC22.5-PCR 0 22.5 25.5 17.8 28.9 - 7/8'' UNF
    STC-PCR STC22.7-PCR 0 22.7 24.9 12.0 27.0 - -
    STC-PCR STC23.4-PCR 0 23.4 26.4 17.5 29.3 3/4'' GAS M27, M26 M24, 5/8'' GAS
    STC-PCR STC24-PCR 0 24.0 26.9 18.0 31.0 - -
    STC-PCR STC24.6-PCR 0 24.6 29.5 27.5 34.0 - -
    STC-PCR STC24.7-PCR 0 24.7 27.7 19.0 32.0 1.1/8'' UNF M27, 1'' UNF
    STC-PCR STC25.2-PCR 0 25.2 29.2 19.0 33.0 - -
    STC-PCR STC26.6-PCR 0 26.6 29.7 26.3 31.6 7/8'' UNF 3/4'' GAS
    STC-PCR STC28-PCR 0 28.0 30.9 19.0 35.3 M30 M27, M28
    STC-PCR STC29.2-PCR 0 29.2 31.2 12.7 34.7 - M22 x 2
    STC-PCR STC30-PCR 0 30.0 32.6 15.2 36.7 M33, 1'' GAS M30
    STC-PCR STC30.5-PCR 0 30.5 33.3 14.5 37.0 - 7/8'' GAS
    STC-PCR STC31.1-PCR 0 31.1 34.3 17.5 38.1 1.3/8'' UNF -
    STC-PCR STC31.1B-PCR 0 31.1 34.4 19.0 38.1 M35 1.1/4'' UNF
    STC-PCR STC31.6-PCR 0 31.6 36.3 24.1 40.2 - 1.5/16'' UNF
    STC-PCR STC33.3-PCR 0 33.3 34.4 9.5 38.1 - -
    STC-PCR STC33.3B-PCR 0 33.3 37.2 22.2 41.6 1.1/2'' UNF 1.1/8'' GAS
    STC-PCR STC33.6-PCR 0 33.6 37.9 12.0 42.7 - -
    STC-PCR STC33.9-PCR 0 33.9 38.3 24.5 42.3 - -
    STC-PCR STC33.9B-PCR 0 33.9 37.3 12.3 42.2 1.5/8'' UNF 1.3/8'' UNF
    STC-PCR STC34.9-PCR 0 34.9 36.4 8.2 42.7 - -
    STC-PCR STC35.9-PCR 0 35.9 40.2 24.5 44.1 - -
    STC-PCR STC36.3-PCR 0 36.3 38.3 12.0 42.3 - -
    STC-PCR STC36.9-PCR 0 36.9 40.6 22.5 44.0 1.1/4'' GAS 1.1/8'' GAS
    STC-PCR STC38.6-PCR 0 38.6 40.6 12.7 44.5 - 1.1/2'' UNF
    STC-PCR STC39.6-PCR 0 39.6 42.7 18.5 47.6 M42, M45, 1.3/8'' GAS 1.3/8'' GAS
    STC-PCR STC40.8-PCR 0 40.8 44.7 24.0 49.0 - -
    STC-PCR STC41.4-PCR 0 41.4 44.8 19.0 49.2 M45 1.1/4'' GAS
    STC-PCR STC42.5-PCR 0 42.5 44.8 12.6 50.7 - -
    STC-PCR STC43.4-PCR 0 43.4 48.5 24.5 53.3 - -
    STC-PCR STC44.1-PCR 0 44.1 46.7 18.4 49.8 - -
    STC-PCR STC44.4-PCR 0 44.4 47.7 19.0 51.0 1.7/8'' UNF - 1.1/2'' GAS M45 x 1.5/2/3
    STC-PCR STC45.2-PCR 0 45.2 49.0 24.5 53.4 1.1/2'' GAS 1.3/8'' GAS
    STC-PCR STC45.9-PCR 0 45.9 46.3 9.5 50.8 M48 -
    STC-PCR STC46-PCR 0 46.0 50.0 24.8 54.0 - -
    STC-PCR STC47.2-PCR 0 47.2 51.9 24.0 55.8 - -
    STC-PCR STC47.5-PCR 0 47.5 50.3 25.0 54.0 - -
    STC-PCR STC48-PCR 0 48.0 52.7 25.4 57.1 - -
    STC-PCR STC48.6-PCR 0 48.6 51.2 18.7 55.5 M52 1.1/2'' GAS
    STC-PCR STC49.8-PCR 0 49.8 54.0 24.3 58.0 M52 1.1/2'' GAS
    STC-PCR STC51.1-PCR 0 51.1 54.4 25.0 57.0 - -
    STC-PCR STC51.5-PCR 0 51.5 54.1 18.5 58.3 - -
    STC-PCR STC53.5-PCR 0 53.5 57.0 25.1 62.4 M56, M55 1.3/4'' GAS
    STC-PCR STC54-PCR 0 54.0 58.4 24.5 62.4 - -
    STC-PCR STC55-PCR 0 55.0 61.0 25.0 65.0 - -
    STC-PCR STC55.4-PCR 0 55.4 58.8 25.1 65.0 M60, M58, 2'' GAS M58
    STC-PCR STC57.5-PCR 0 57.5 57.6 12.8 63.6 - -
    STC-PCR STC59.3-PCR 0 59.3 67.3 31.7 70.3 - -
    STC-PCR STC59.6-PCR 0 59.6 62.6 24.6 66.7 M62, M60 M60, 2'' GAS
    STC-PCR STC62-PCR 0 62.0 66.4 28.0 71.0 - -
    STC-PCR STC63.3-PCR 0 63.3 69.8 25.4 73.0 - -
    STC-PCR STC64.5-PCR 0 64.5 67.3 15.8 70.6 - -
    STC-PCR STC68.1-PCR 0 68.1 70.9 19.0 74.6 - -
    STC-PCR STC70-PCR 0 70.0 75.8 25.4 79.4 M76, M75, 2.1/2'' GAS -
    STC-PCR STC74-PCR 0 74.0 77.0 18.7 82.5 - -
    STC-PCR STC74B-PCR 0 74.0 76.8 24.4 80.0 - -
    STC-PCR STC76.8-PCR 0 76.8 82.2 25.4 85.7 - -
    STC-PCR STC77.1-PCR 0 77.1 80.7 19.0 85.7 - 2.1/2'' GAS
    STC-PCR STC80-PCR 0 80.0 86.1 25.1 89.8 3'' GAS -
    STC-PCR STC84.2-PCR 0 84.2 90.8 28.0 94.5 - 3'' GAS
    STC-PCR STC85.3-PCR 0 85.3 88.0 19.0 92.0 - -
    STC-PCR STC87.5-PCR 0 87.5 93.6 34.3 96.7 - -
    STC-PCR STC88.1-PCR 0 88.1 93.3 28.6 96.5 - -
    STC-PCR STC92.1-PCR 0 92.1 97.0 32.0 100.0 - -
    STC-PCR STC93.5-PCR 0 93.5 100.3 26.5 107.5 - -
    STC-PCR STC94.5-PCR 0 94.5 100.6 34.5 103.6 - -
    STC-PCR STC96.5-PCR 0 96.5 102.0 31.0 110.0 - -
    STC-PCR STC98-PCR 0 98.0 102.0 24.7 107.2 - -
    STC-PCR STC98.2-PCR 0 98.2 103.3 28.8 106.0 - -
    STC-PCR STC101-PCR 0 101.0 107.0 28.6 109.0 - -
    STC-PCR STC101.9-PCR 0 101.9 107.5 28.6 109.0 - -
    STC-PCR STC106.7-PCR 0 106.7 111.7 28.6 113.3 - -
    STC-PCR STC108-PCR 0 108.0 114.1 35.2 118.5 - -
    STC-PCR STC109-PCR 0 109.0 113.0 27.0 123.0 - -
    STC-PCR STC110-PCR 0 110.0 115.0 28.0 118.5 - -
    STC-PCR STC111.5-PCR 0 111.5 117.6 35.0 122.0 - -
    STC-PCR STC112.1-PCR 0 112.1 114.3 28.6 116.8 - -
    STC-PCR STC124-PCR 0 124.0 128.0 23.0 134.0 - -
    STC-PCR STC129-PCR 0 129.0 135.1 36.5 139.5 - -
    STC-PCR STC133-PCR 0 133.0 137.0 22.0 143.0 - -
    STC-PCR STC139.5-PCR 0 139.5 145.6 36.5 150.0 - -
    STC-PCR STC142.5-PCR 0 142.5 148 33 159.5 - -
    STC-PCR STC146.8-PCR 0 146.8 151 30.5 159.5 - -
    STC-PCR STC153-PCR 0 153 161.5 29.6 178.9 - -
    STC-PCR STC157-PCR 0 157 163 38 172 - -
    STC-PCR STC164-PCR 0 164 166 21.5 174 - -
    STC-PCR STC168-PCR 0 168 190 38 172 - -
    STC-PCR STC168B-PCR 0 168 172 21.6 179 - -
    STC-PCR STC173-PCR 0 173 181.3 38.5 195 - -
    STC-PCR STC177-PCR 0 177 185 38 195
    STC-PCR STC187.5-PCR 0 187.5 191.5 21.7 197.5
    STC-PCR STC192-PCR 0 192 200 38 215
    STC-PCR STC199-PCR 0 199 204 38 214
    STC-PCR STC203.5-PCR 0 203.5 208.5 26 216
    STC-PCR STC207.5-PCR 0 207.5 212 26.5 223
    STC-PCR STC216-PCR 0 216 223.6 29.1 241.5
    STC-PCR STC221.5-PCR 0 221.5 230 23.7 237
    STC-PCR STC223-PCR 0 223 230.5 38 240
    STC-PCR STC232-PCR 0 232 239 46 250
    STC-PCR STC238-242-PCR 0 238 242 30 246
    STC-PCR STC238-PCR 0 238 250 46 263
    STC-PCR STC249-PCR 0 249 254 46 264
    STC-PCR STC250-PCR 0 250 261 46 280
    STC-PCR STC270-PCR 0 270 281 43 297
    STC-PCR STC278-PCR 0 278 286 46 304
    STC-PCR STC284-PCR 0 284 293 46 315
    STC-PCR STC292-PCR 0 292 299 46 315
    STC-PCR STC298-PCR 0 298 301 23 314
    STC-PCR STC313-PCR 0 313 325 50.5 340
